CannaBass™ CB3010N-8
$259.99
$289.9910% offCannabass Series
Eminence is proud to introduce the CannaBass™ CB3010N-8. Engineered with the modern player in mind, the CB3010N-8 features organic and natural damping properties delivering a cleaner, more authentic sound through a unique combination of cutting-edge speaker technology, the superior qualities of a hemp dust cap, and a proprietary CBD coating.
The CannaBass™ CB3010N-8’s black paper cone features a CBD coating on the back that supplies a damping quality and enhances the smooth frequency response. The natural material in the green hemp dust cap makes it an eco-friendly choice and provides additional natural damping for the CB3010N-8, creating a more pristine sound.
The CannaBass™ CB3010N-8 is ideal for players who demand the best sound quality. Featuring a high-temperature Neo magnet, the CannaBass™ CB3010N-8 is powerful and lightweight yet durable, offering a steady flux field that ensures high-quality sound. With a 6.48mm xMax and 900-watt music power rating (450W EIA), the CB3010N-8 is expertly voiced to provide a loud, low distortion, low-frequency range. It delivers a powerful, high-quality sound that is perfect for modern musicians. Additionally, our three-inch inside/outside wound voice coil on a vented fiberglass bobbin provides lower power compression and distortion for a more accurate and authentic sound.
SPECIFICATION | |
Nominal Basket Diameter | 10", 254 mm |
Nominal Impedance* | 8 Ω |
Power Rating* | |
Program Power | 900 W |
Watts | 450 W |
Resonance | 41.62 Hz |
Usable Frequency Range | 43 Hz - 3.4 kHz |
Sensitivity* | 94 dB |
Magnet Weight | 11 oz. |
Gap Height | 0.365", 9.27 mm |
Voice Coil Diameter | 3", 76.2 mm |
THIELE & SMALL PARAMETERS | |
Resonant Frequency (fs) | 41.62 Hz |
DC Resistance (Re) | 5.62 Ω |
Coil Inductance (Le) | 0.62m H |
Mechanical Q (Qms) | 7.95 |
Electromagnetic Q (Qes) | 0.25 |
Total Q (Qts) | 0.25 |
Compliance Equivalent Volume (Vas) | 55.22 liters / 1.95 cu.ft. |
Peak Diaphragm Displacement Volume (Vd) | 244.23 cc |
Mechanical Compliance of Suspension (Cms) | 0.28 mm/N |
BL Product (BL) | 17.22 T-M |
Diaphragm Mass Inc. Airload (MMs) | 51.42 grams |
Efficiency Bandwidth Product (EBP) | 163.48 |
Maximum Linear Excursion (Xmax) | 6.48 mm |
Surface Area of Cone (Sd) | 376.9 cm2 |
Maximum Mechanical Limit (Xlim) | 14.16 mm |
MOUNTING INFORMATION | |
Recommended Enclosure Volume | |
Sealed | Not Recommended |
Vented | Acceptable |
Driver Volume Displaced | 64.68 cu.in. / 1.06 liters |
Overall Diameter | 10.25", 260.35 mm |
Baffle Hole Diameter | 9.12", 231.65 mm |
Front Sealing Gasket | Yes |
Rear Sealing Gasket | Yes |
Mounting Holes Diameter | 0.28", 7.112mm |
Mounting Holes B.C.D. | 9.73", 247.14mm |
Depth | 4.25", 108 mm |
Net Weight | 7.1 lbs, 3.22 kg |
Shipping Weight | 8.9 lbs, 4.04 kgs |
MATERIALS OF CONSTRUCTION | |
Coil Construction | Inside/Outside copper voice coil |
Coil Former | Fiberglass former |
Magnet Composition | Neodymium magnet |
Core Details | Vented core |
|
|
Basket Materials | Cast Aluminum Basket |
Cone Composition | CBD treated paper cone |
Cone Edge Composition | Cloth cone edge |
Dust Cap Composition | Hempylene paper dustcap |
