SD28 Soft Dome Tweeter

The Eminence SD28 soft-dome tweeter offers unmatched performance to value in an ultra-compact design. With an overall diameter of less than 1.5 inches, this 4-ohm silk dome tweeter delivers smooth high-frequency reproduction from 1.5 to 20 kHz. Perfect for home stereo, car audio, ATV, RV, or any other application where space is limited.

SPECIFICATION
Type	N/A
Throat Size	", mm
Dispersion	60°
Power Rating	10W (AES), 20W (EIA-
Nominal impedance	4Ω
Minimum impedance	3.5 Ω @ 4.4 kHz
Sensitivity	92.5 dB
Resonance	1.5 kHz
Usable Frequency Range	1500 Hz – 20 kHz
Low Rec. Crossover	1.5 kHz
W x H x D (in)	1.48" x 1" x "
W x H x D (mm)	37.6 x 25.4 x mm
Cut Out	Rear mount,
Weight	0.1lbs, 0.05kg
Material	N/A
