F151M-8 1" Ceramic ring radiator compression driver

Despite its minute size, the Eminence F151M-8 ring radiator compression driver delivers monumental performance. Utilizing a phase plug design that improves the distribution of forces over the diaphragm surface results in a driver with lower distortion, smoother frequency response, and increased sensitivity as compared to conventional ring radiator designs.

SPECIFICATION
Throat Size	1", 25.4mm
Nominal Impedance*	8Ω
Minimum Impedance	5.1 ohm @ 5.5 kHz
Power Rating**	46 W (AES)
Resonance	1.03kHz
Usable Frequency Range	1800Hz-20kHz
Recommended Crossover	1.8 kHz @ 12 dBkHz
Sensitivity***	108.9
Magnet Material	Ferrite
Magnet Weight	15oz, 0.43kg
Voice Coil Diameter	1.5" / 38.1mm
Voice Coil Former	Polyimide
Diaphragm Material	Mylar
DC Resistance (Re)	4.1Ω
MOUNTING INFORMATION
Overall Diameter	3.94", 100.1mm
Driver Volume Displaced	0.035 cu.ft., 0.21 liters
Depth	1.65", 41.9mm
Weight	2.5 lbs, 1.12 kg
Mounting Thread	N/A
Mounting Holes Diameter	2X 1/4-20
Mounting Holes B.C.D.	3 in., 76.2 mm
