CANNABIS REX™ 12" Lead / Rhythm Guitar Speaker- American

The Eminence Cannabis Rex™ guitar speaker lets your laid-back style come through. Clean and full, with lots of body and sparkle. Smokey smooth with high-end definition. Country, Jazz or Classical guitarists take notice.

Also check out the CANNABIS REX-16 12" Lead / Rhythm Guitar Speaker - American

SPECIFICATION
Nominal Basket Diameter	12", 305 mm
Nominal Impedance*	8 Ω
Power Rating*
Program Power	N/A
Watts	50 W
Resonance	96 Hz
Usable Frequency Range	80 Hz - 4.5 kHz
Sensitivity*	101.8 dB
Magnet Weight	38 oz.
Gap Height	0.312", 7.9 mm
Voice Coil Diameter	1.75", 44 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs)	96 Hz
DC Resistance (Re)	6.56 Ω
Coil Inductance (Le)	0.44m H
Mechanical Q (Qms)	9.28
Electromagnetic Q (Qes)	0.69
Total Q (Qts)	0.64
Compliance Equivalent Volume (Vas)	45.48 liters / 1.61 cu.ft.
Peak Diaphragm Displacement Volume (Vd)	44.7 cc
Mechanical Compliance of Suspension (Cms)	0.11 mm/N
BL Product (BL)	11.8 T-M
Diaphragm Mass Inc. Airload (MMs)	24 grams
Efficiency Bandwidth Product (EBP)	139
Maximum Linear Excursion (Xmax)	0.8 mm
Surface Area of Cone (Sd)	532.4 cm2
Maximum Mechanical Limit (Xlim)	N/A
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed	Acceptable
Vented	Acceptable
Driver Volume Displaced	0.071 cu.ft. / 2 liters
Overall Diameter	12.03", 305.6 mm
Baffle Hole Diameter	11.07", 281.2 mm
Front Sealing Gasket	Yes
Rear Sealing Gasket	Yes
Mounting Holes Diameter	0.25", 6.4mm
Mounting Holes B.C.D.	11.59", 294.4mm
Depth	5.1", 129.5 mm
Net Weight	8.2 lbs, 3.72 kg
Shipping Weight	9.8 lbs, 4.45 kgs
MATERIALS OF CONSTRUCTION
Coil Construction	Copper voice coil
Coil Former	Paper former
Magnet Composition	Ferrite magnet
Core Details	Non-vented core

Basket Materials	Pressed steel basket
Cone Composition	Hemp paper cone
Cone Edge Composition	Paper cone edge
Dust Cap Composition	Zurette dust cap
